Portable Syn Gas Analyzer BI 7230

BI 7230 Portable Syn-Gas Analyzer System has been designed considering the flexibility required in the environments that characterize syn gas and bio-mass applications.

The analyzer uses high-stability infrared sensors for the simultaneous measurement of CO, CO2 and CH4. In addition, the analyzer can also be supplied with long-life electrochemical sensor for H2.
All sensors are temperature-compensated for maximum analytical stability. Auto calibration functionality allows easy calibration without user intervention.

Category:

Features

  • 32-Bit Contex-M3 ARM Processor
  • 5.7″ QVGA TFT Touch Screen Display
  • Touch-3screen display for gas reading
  • Built-in sample pump or pressure regulator
  • Tried and tested technology with proven reliability
  • High range on each channel available (up to 100%)
  • Automatic moisture removal system included
  • RS 232 interface for data logging
  • PTFE sample lines & sample components (where prudent)

Specifications

Method of Detection NDIR infrared sensor for CO, CO2, CH4
Electrochemical sensor for O2 & H2
Ranges Available
O2 0-25%, 0-50%, 0-100%, Resolution: 0.10%
CO 0-10%, 0-50%, 0-100%, Resolution: 0.10%
CO2 0-10%, 0-50%, 0-100%, Resolution: 0.10%
CH4 0-50%, 0-100%, Resolution: 0.10%
H2 0-50%, Resolution: 0.10%
Accuracy & Repeatability ± 2% of reading for all gases
Drift Less than 2% of full scale per month
Response Time (T-90) 20-30 seconds
Ambient Temperature Range 4 to 50°C
Power 12V/24V DC adaptor
Output Options RS 232 interface for data logging
